About the Project

Radius wedge wire celling grilles, installed at Warsaw University, Poland. This design provided a modern, light weight ceiling that also concealed the electric lighting, and was easy to install.

Progress Architecture

Radius wedge wire grill is a Progress Architecture product, supplied and distributed in the UK and Ireland by Locker Architectural.

Open post
Radius Architectural wedge wire with black powder coating

Radius Architectural Wedge Wire

Radius Architectural Wedge Wire Grille


Radius Architectural Wedge Wire

Radius Z10105 A5Sa 8,4x2 Pro-ZINAL coated mild steel with black, powder coated finish

Specification

Wedge Wire Material Stainless Steel or *Pro-ZINAL® Coated Mild Steel
Wedge Profile (w x h) 3.5 x 4.5, 4.5 x 4.5, 5.0 x 6.0 mm
Aperture (A) From 2 mm to 50 mm
Support Rods Dimensions and pitch to suit load
Framing As required subject to application
Finish Bare metal or Powder Coat (specify RAL No. for colour)

Please note: The above information is a guide to the wide range of options available. Contact our sales team for help in selecting the correct product for your application.

*Pro-ZINAL® is a metallic coating of Zinc and Aluminium alloy, which is used to protect traditional Carbon steel. It ensures durability and a high resistance to corrosion, even in welded areas.

Radius Architectural Wedge Wire pdf specification sheet

Radius Wedge Wire Panel Construction

Radius wedge wire panel construction

Radius Colour Examples

Radius Colour Examples: Black, Copper, Silver, Gold

Radius wedge wire features a profile with curved sides. This reduces overall weight whilst maintaining structural integrity and helps to prevent the build up of dirt on the wedge.

Radius Colour Examples: Black, Copper, Silver, Gold. Specify the RAL number for your required colour.

Typical Applications

Balustrade infill panels, façades, air distribution and drainage grilles, floor and stair grilles, fountain grilles, ceiling grilles, solar shading and bespoke applications which include seating and street furniture.

With comprehensive in-house 3D design facilities, we are able to offer a complete package from development of the architectural wire mesh specification through design, fabrication, and delivery to site as and when required for installation.
