Turtle Bay Restaurant ceiling infill

Turtle Bay Restaurant, Winchester

Open post

Woodbridge Vent Shroud

Woodbridge Vent Shroud


Woodbridge-Vent-shroud-6
Woodbridge-Vent-shroud-4
Woodbridge-Vent-shroud-3
Woodbridge-Vent-shroud-2
Woodbridge-Vent-shroud-5
previous arrow
next arrow
Woodbridge-Vent-shroud-6
Woodbridge-Vent-shroud-4
Woodbridge-Vent-shroud-3
Woodbridge-Vent-shroud-2
Woodbridge-Vent-shroud-5
previous arrow
next arrow

About the Project

Soho XL Expanded Mesh, powder coated to RAL 1002, supplied by Locker Architectural. Fabrication and installation works carried out by Air 3 Limited.

The mesh has been radiused and used to screen off two vertical ducts, fixed using semi-circular brackets. To radius more easily, the long way of the aperture runs vertically, whereas normally this runs horizontally.



Open post
Sainsbury's, Brentwood Essex Cladding - Car Park Soho XL

Sainsbury’s, Brentwood, Essex

Sainsbury's, Brentwood, Essex


sains-brentwood1-large
sains-brentwood2-large
sains-brentwood3-large
sains-brentwood4-large
previous arrow
next arrow
sains-brentwood1-large
sains-brentwood2-large
sains-brentwood3-large
sains-brentwood4-large
previous arrow
next arrow

About the Project

Soho XL powder coated expanded metal car park façade at Sainsburys Brentwood. The main façade is designed to appear as a seamless, randomly undulating ribbon of mesh. In reality the mesh panels are carefully designed to avoid any visible panelisation or connection. Curved metal banding seamlessly holds the panels in place.

Two additional flat clad headlight screens covered in similar expanded metal bands are designed to mimic the main façades, and protect nearby housing from intrusive car headlights. The deceptive curvilinear form provides an elegant architectural screen, which economically both enhances and disguises the functional steel frame behind.

Architect: CHQ Architects
