Category: Traditional Pre-crimped Woven Meshes

Open post
Portland Manilla 60 pre-crimped Architectural Mesh

Portland Manilla 60 Pre-Crimped Architectural Wire Mesh

Portland Manilla 60 Pre-Crimped Architectural Wire Mesh

A medium density, flat wire, intermediate crimp woven mesh, typically supplied in Stainless Steel and used for balustrades, facades, decorative radiator grilles, security panels and elevator cladding.

Hebrides Traditional Pre-crimped Wire Mesh

Specifications

MATERIAL STAINLESS STEEL 316L
APERTURE 60 mm WIRE 5 x 1.2 mm flat wire
OPEN AREA 55% WEIGHT 3.6 kg/m²

Portland Manilla 60 Pre-Crimped Wire Mesh: printable specification sheet with 1:2 scale image.

Submit Enquiry.

Material Availability

Made to order in Mild or Stainless Steel, Aluminium, Phosphor Bronze, Copper and Brass.

Finishes

Powder coated finish available, provided the mesh is secured in a frame.

Fabrication

Locker Architectural can supply this mesh secured in a frame of your choosing.

Progress Architecture

Portland Manilla 60 architectural wire mesh is a Progress Architecture product, supplied and distributed in the UK and Ireland by Locker Architectural.

Open post
Churchill 25/25 SS wire mesh

Churchill 25/25 Traditional Pre-crimped Wire Mesh

Churchill 25/25 Traditional Pre-crimped Wire Mesh

A medium density, crimped woven mesh, typically supplied in Stainless Steel and used for balustrades, facades, brie soleil, security panels and drapes.

Churchill 25/25 Traditional Pre-crimped Wire Mesh

Specifications

MATERIAL Stainless Steel
APERTURE 25 x 25 mm WIRE 2.5 mm
OPEN AREA 83% WEIGHT 2.9 kg/m²

Churchill 25/25 Pre-Crimped Wire Mesh: printable specification sheet with 1:1 scale image.

Submit Enquiry.

A range of materials, aperture sizes and wire diameters are available.

Material Availability

Generally available in grades 316 and 304 stainless. Can also be made to
order in Galvanised Steel, Aluminium, Brass and Phosphor Bronze.

Finishes

Powder coated finish available, provided the mesh is secured in a frame.

Fabrication

Locker Architectural can supply this mesh secured in a frame of your choosing.

Open post
Churchill 46/46 pre-crimped wire mesh

Churchill 46/46 Traditional Pre-crimped Wire Mesh

Churchill 46/46 Traditional Pre-crimped Wire Mesh

A medium density, crimped woven mesh, typically supplied in Brass and used for balustrades, facades, brie soleil, security panels and drapes.

Churchill 46/46 Traditional Pre-crimped Wire Mesh

Specifications

MATERIAL BRASS
APERTURE 46 x 46 mm WIRE 5 mm
OPEN AREA 81.4% WEIGHT 7.54 kg/m²

Churchill 46/46 Pre-Crimped Wire Mesh: printable specification sheet with 1:1 scale image.

Submit Enquiry.

A range of materials, aperture sizes and wire diameters are available.

Material Availability

Generally available in Brass. Can also be made to order in 304 and 316 Stainless Steel, Galvanised Steel, Aluminium and Phosphor Bronze.

Finishes

Powder coated finish available, provided the mesh is secured in a frame.

Fabrication

Locker Architectural can supply this mesh secured in a frame of your choosing.

Open post
Jacobson 612 Silver Architectural Mesh Perpendicular

Jacobson 612 Traditional Pre-Crimped Wire Mesh

Jacobson 612 Traditional Pre-Crimped Woven Mesh

Heavy, opaque, and opulent, perfect for wall and lift cladding.

PDF Technical Sheet

The mesh is formed from a combination of flat and round wires. The end result is a robust, completely opaque product, more visually similar to embossed sheet metal than a woven mesh. Perfect for high-end projects.

Dependent on your application and criteria, Jacobson 612 is available in the following materials:

  • Stainless Steel
  • Aluminium
  • Copper
  • Brass

A secondary powder-coated, or anodised (aluminium only) finish can also be applied in a myriad of different colours and effects.

Metals in the warp and weft directions (horizontal and vertical) can be mixed to achieve stunning visual effects e.g. brass wire running vertically and stainless steel running horizontally.

Jacobson 612 Traditional Pre-Crimped Wire Mesh is a Codina Architectural product, supplied and distributed in the UK by Locker Architectural.

Jacobson 612 Silver Architectural Mesh Perpendicular
Jacobson 612 Silver Architectural Mesh Perpendicular

Mesh shown is Natural Finish Aluminium

Standard Panel Sizes

Bespoke panel sizes are available on request.

Applications

Jacobson 612 is ideal for a number of different applications, including but not limited to:

Lift Enclosures

Decorative Metalwork

Locker manufacture the finished article, including cutting to size, framing, finishing, and ancillary components.

In case of any bespoke requirements, our experienced in-house design and fabrication team will develop and supply the system and components you need to install goods on-site

Contact our sales team to talk to us about your specific requirements.

Open post
Lucerne-5/16-SS-Mesh

Lucerne 5/1.6 Traditional Pre-Crimped Wire Mesh

Lucerne 5-1.6 Metal Architectural Mesh

Lucerne 5-16 wire mesh

Sample shown is Stainless Steel

Specifications

Pattern Name : Lucerne 5/1.6
Material : Stainless Steel AISI 316L. DIN 1.4404

Open Area : 56%
Wire Diameters : 1.6mm x 1.6mm
Aperture : 5.0mm x 5.0mm
Thickness of Mesh : 3.2mm
Weight : 5.12Kg / m2
Maximum Mesh Width : 2000mm
Standard Panel Size : 3000mm x 2000mm
Standard Fixing System : Angle Frame Secured with Flat Strip

Locker manufacture the finished article, including cutting to size, framing, finishing, and ancillary components.

In case of any bespoke requirements, our experienced in-house design and fabrication team will develop and supply the system and components you need to install goods on-site.

Contact our sales team to talk to us about your specific requirements.

Open post

Churchill 11/11 Copper

Churchill 11/11 Copper Wire Mesh

A medium-density, intermediate-crimp woven mesh.

Typically supplied in copper or brass, and used for bar grilles, room dividers, and other ornamental metalwork.

Material Availability

Readily available in both Copper and Brass. Made to order in other materials such as stainless steel, mild steel, etc.

Finishes

Powder coated finish available, provided the mesh is secured in a frame.

Fabrication

Locker Architectural can supply this mesh secured in a frame of your choosing.

Enquire about this mesh

Please do not hesitate to get in touch to discuss your project, our early involvement often saves substantial time later on.

Open post
nelson wire mesh

Nelson 5/1.6 Traditional Pre-Crimped Wire Mesh

Nelson 5/1.6 Traditional Pre-crimped Wire Mesh

A medium density, pre-crimped woven mesh, typically supplied in Stainless Steel and used for screening and ornamental metalwork.

Nelson 5/1.6 Traditional Pre-crimped Wire Mesh

Specifications

MATERIAL STAINLESS STEEL 316L
APERTURE 5 x 5 mm WIRE 1.6 mm
OPEN AREA 58% WEIGHT 6.4 kg/m²

Nelson 5/1.6 Pre-Crimped Wire Mesh: printable specification sheet with 1:1 scale image.

Submit Enquiry.

A range of aperture sizes are available, from 1 mm down to 50 micron.

Material Availability

Stocked in Stainless Steel.

Made to order in Mild Steel, Aluminium, Phosphor Bronze, Copper and Brass.

Finishes

Powder coated finish available, provided the mesh is secured in a frame.

Fabrication

Locker Architectural can supply this mesh secured in a frame of your choosing.

Open post
hebrides woven wire mesh

Hebrides Traditional Pre-Crimped Wire Mesh

Hebrides Traditional Pre-crimped Wire Mesh

A medium density, flat wire, intermediate crimp woven mesh, typically supplied in Stainless Steel or Brass and used for premium bar grilles, bespoke room dividers and other ornamental metalwork.

Hebrides Traditional Pre-crimped Wire Mesh

Specifications

MATERIAL STAINLESS STEEL 316L
APERTURE 24 mm WIRE 5 x 1.2 mm flat wire
OPEN AREA 45% WEIGHT 5.08 kg/m²

Hebrides Pre-Crimped Wire Mesh: printable specification sheet with 1:1 scale image.

Submit Enquiry.

Material Availability

Made to order in Mild or Stainless Steel, Aluminium, Phosphor Bronze, Copper and Brass.

Finishes

Powder coated finish available, provided the mesh is secured in a frame.

Fabrication

Locker Architectural can supply this mesh secured in a frame of your choosing.

Open post
humber woven wire mesh

Humber Traditional Pre-Crimped Wire Mesh

Humber Traditional Pre-crimped Wire Mesh

A medium density, pre-crimped woven mesh, typically supplied in Stainless Steel and used for balustrading.

Humber Traditional Pre-crimped Wire Mesh

Specifications

MATERIAL STAINLESS STEEL
APERTURE 22.5 x 6 mm WIRE 2 mm
OPEN AREA 69% WEIGHT 4.2 kg/m²

Humber Pre-Crimped Wire Mesh: printable specification sheet with 1:1 scale image.

Submit Enquiry.

Material Availability

Made to order in Mild or Stainless Steel, Aluminium, Phosphor Bronze, Copper and Brass.

Finishes

Powder coated finish available, provided the mesh is secured in a frame.

Fabrication

Locker Architectural can supply this mesh secured in a frame of your choosing.

Open post
portland-33-traditional-precrimped-architectural-wire-mesh

Portland 3/3 Traditional Pre-Crimped Wire Mesh

Portland 3/3 Traditional Pre-crimped Wire Mesh

A dense, flat wire woven mesh, typically supplied in Stainless Steel or Brass and used for decorative screening or lift cladding.

Portland 3/3 Traditional Pre-crimped Wire Mesh

Specifications

MATERIAL STAINLESS STEEL 404
APERTURE 3 x 3 mm WIRE 3 x 1 mm
OPEN AREA 25% WEIGHT  7.6 kg/m²

Portland 3/3 Pre-Crimped Wire Mesh: printable specification sheet with 1:1 scale image.

Submit Enquiry.

Material Availability

Made to order in Stainless Steel, Mild Steel, Aluminium, Phosphor Bronze, Copper and Brass.

Finishes

Powder coated finish available, provided the mesh is secured in a frame.

Fabrication

Locker Architectural can supply this mesh secured in a frame of your choosing.
