Manhattan XL Architectural Expanded Metal
Download PDF Technical Sheet
Expanded metal mesh combines strength and rigidity with a high percentage of open area for air flow, making it suitable for a wide range of decorative and functional applications. The precise level of screening and open area can be tailored to your requirements.
Dependent on your application and criteria, Manhattan XL expanded metal mesh is available in the following materials:
- Mild Steel
- Pre-galvanised Steel
- Aluminium
- Corten Steel, also known as weathering steel See the image of the sample below
A secondary powder-coated, or anodised (aluminium only) finish can also be applied in a myriad of different colours and effects.
This sample of Manhattan XL expanded metal mesh in Corten steel shows the finish patina after 3 weeks of exposure to the British weather.
Specifications
| Pitch (mm) | Thickness (mm) | Weight (Kg/m2) | Open Area (%) | ||||
|---|---|---|---|---|---|---|---|
| Long way | Short Way | Material | Total | Aluminium | Mild Steel | Visual | Air flow |
| 250 | 90 | 1.5 | 39 | 2.7 | 7.9 | 41 | 78 |
| 250 | 90 | 2 | 39 | 3.6 | 10.5 | 41 | 78 |
| 250 | 90 | 3 | 39 | 5.4 | 15.7 | 41 | 78 |
| All specifications are subject to manufacturing tolerances | |||||||
Standard Panel Sizes
- 1,000mm x 2,000mm
- 1,250mm x 2,500mm
- 1,500mm x 3,000mm
Bespoke panel sizes are available on request.
Applications
Manhattan XL has a large aperture and open area for air flow and light penetration, with a good level of screening.
This makes it ideal for a number of different applications, including but not limited to:
Locker manufacture the finished article, including cutting to size, framing, finishing, and ancillary components.
In case of any bespoke requirements, our experienced in-house design and fabrication team will develop and supply the system and components you need to install goods on-site.
Contact our sales team to talk to us about your specific requirements.
