Rope Diamond Knotted Mesh

Rope Diamond Knotted Mesh


Material Stainless Steel 304/316
Cable 1.6 mm Pitch 30 x 30 mm
Open Area 90% Weight 1.28 kg/m²
Max Width 4500 mm

Rope Diamond Knotted Mesh: printable specification sheet with 1:1 scale image

For measuring purposes the knotted mesh should be stretched to create a 90° angle at the top of the diamond.


Stainless Steel 304. Also available in Stainless Steel 316. Range available is from 20 mm up to 120 mm pitch.

Typical Applications

Bird screening, animal enclosures, protective netting, balustrading and tension façades.

Locker is a UK based supplier of architectural wire mesh products certified to BS EN ISO 9001:2015.

With comprehensive in-house 3D design facilities we are able to offer a complete package from development of the architectural wire mesh specification through design, fabrication, supply and installation of the finished screens.
