Chelsea Architectural Expanded Metal

Chelsea Architectural Expanded Metal


Chelsea Architectural Expanded Metal

Sample: Yellow Powder Coated Finish

Expanded Metals Diagram

Specifications

LWD SWD THK STR OPEN AREA WEIGHT (ALUMINIUM)
10 mm 7 mm 0.8 mm 1.5 mm 46% 0.95 kg/m²
10 mm 7 mm 1 mm 1.5 mm 46% 1.15 kg/m²
10 mm 7 mm 1.5 mm 1.5 mm 46% 1.7 kg/m²
10 mm 7 mm 2 mm 1.5 mm 46% 2.4 kg/m²

Chelsea Expanded Metal: printable specification sheet with 1:1 scale image.

Availability

Aluminium natural, painted, powder coated or anodised. Interior and exterior grades of stainless steel.

Typical Applications

Particularly suitable for the creation of roof-gardens as the hole diameter and material have been carefully designed to support plant growth.

Locker is a UK based supplier of architectural wire mesh products certified to BS EN ISO 9001:2015 and Achilles 'Building Confidence' Level 4.

With comprehensive in house 3D design facilities we are able to offer a complete package from development of the architectural wire mesh specification through design, fabrication, supply and installation of the finished screens.
